Positioning

Position control modules

POS-121POS-121

  • Simple positioning unit

  • Analogue input signal

  • Analogue feedback signal

  • Stroke dependent deceleration

  • Robust and simple to adjust

  • Optional with integrated power stage

POS-121 (rev 8)    Appendix: Power stage PEXT4

POS-122POS-122

  • Simple positioning unit

  • Eight selectable positions and speed

  • Analogue feedback signal

  • Stroke dependent deceleration

  • Robust and simple to adjust

  • Optional with integrated power stage

 POS-122  (rev. 10)

POS-123 (new software version)POS-123

  • Universal positioning unit

  • Analogue input signals for position and speed

  • Analogue feedback signal

  • Stroke dependent deceleration or NC mode (speed controlled)

  • Different options for improved accuracy

  • Robust and simple to adjust

  • Optional with integrated power stage


 POS-123-1121

POS-123SSIPOS-123SSI (new software version)

  • Universal positioning unit

  • Analogue input signals for position and speed

  • SSI sensor feedback (0,001 mm resolution)

  • Analogue SSI output useable for monitoring

  • Stroke dependent deceleration or NC mode (speed controlled)

  • Different options for improved accuracy

  • Robust and simple to adjust


 POS-123-1121

POS-123PDPPOS-123PDP

  • Universal positioning unit

  • Profibus DP Schnittstelle

  • Internal profile generation

  • SSI or analogue feedback signal

  • Stroke dependent deceleration or NC mode (speed controlled)

  • Different options for improved accuracy

  • Robust and simple to adjust

POS-123PDP rev 11    Appendix: GSDDatei

POS-124PDPPOS-124PDP

  • NEW: Two axes positioning unit

  • Profibus DP Schnittstelle

  • Internal profile generation

  • Analogue feedback signal

  • Stroke dependent deceleration or NC mode (speed controlled)

  • Different options for improved accuracy

  • Robust and simple to adjust

  • Optional with CanBus interface used for different sensors

POS-124-PDP     Appendix: GSDDatei

PPC-125PDPPPC-125PDP

  • Universal axis contol unit

  • Profibus DP interface

  • Internal profile generation

  • SSI or analogue feedback signals for position and pressure

  • Stroke dependent deceleration or NC mode (speed controlled)

  • p/Q pressure limitation control

  • Different options for improved accuracy

PPC-125 (rev. 8)    Appendix: GSDDatei

POS-127POS-127

  • Positioning unit for high speed double stroke movements

  • Analogue input signals for position and speed

  • Analogue feedback signal

  • Stroke dependent deceleration or NC mode (speed controlled)

  • Robust and simple to adjust

  • Optional with integrated power stage

POS-127 (rev. 8)    Appendix: Power stage PEXT4

SCU-129POS-123

  • Speed control unit for cylinder drives

  • Analogue input signals for position and speed

  • Analogue feedback signal

  • NC mode (speed controlled)

  • Robust and simple to adjust

 SCU-129-1121

|
